PLAN 314-217
Key Specs
2837
sq ft
4
Beds
3
Baths
2
Floors
2
Garages
Cost to Build Reports Only $19.99 for a Limited Time!
This report will provide you cost estimates based on location and building materials.
Phone: 1-877-222-1762
See our Terms & Conditions and Privacy Policy.
PLAN 314-217
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.Plan Description
Full Specs & Features
Height : 26'
Width : 86' 8"
Second Floor: 685 sq/ft
Roof Framing : Conventional
Roof Type : Shingle
Framing : Wood - 2x4
Formal Dining Room
Formal Living Room / Parlor
Main Floor Master Bedroom
Kitchenette Wet Bar
Great Room Living Room
Loft
Main Floor Laundry
Master Sitting Area
Open Floor Plan
Covered Front Porch
Covered Rear Porch
Wrap Around Porch
3rd BR Closet:
12 sq/ft width 6' x depth 2'
Bathroom 2:
51 sq/ft width 10' 4" x depth 5'
Bedroom 2:
200 sq/ft width 16' 8" x depth 12'
Bedroom 2 Closet:
34 sq/ft width 8' x depth 4' 4"
Bedroom 3:
192 sq/ft width 16' x depth 12'
Bedroom 3 Closet:
34 sq/ft width 8' x depth 4' 4"
Breakfast Room:
100 sq/ft width 9' x depth 11' 2"
Dining Room:
192 sq/ft width 16' x depth 12'
Foyer:
156 sq/ft width 13' x depth 12'
Garage:
400 sq/ft width 20' x depth 20'
Garage Storage:
24 sq/ft width 6' 8" x depth 3' 8"
Gathering Room:
336 sq/ft width 20' x depth 16' 10"
Hall Bathroom:
60 sq/ft width 10' x depth 6'
Hall Closet:
8 sq/ft width 4' x depth 2'
Kitchen:
171 sq/ft width 14' 4" x depth 12'
Laundry Room:
40 sq/ft width 5' x depth 8' 2"
Living Room:
192 sq/ft width 16' x depth 12'
Master Bathroom:
127 sq/ft width 11' 9" x depth 10' 10"
Master Bedroom:
247 sq/ft width 13' x depth 19'
Master Closet:
49 sq/ft width 7' 5" x depth 6' 8"
Porch - Front:
341 sq/ft width 62' 2" x depth 5' 6"
Porch - Left:
67 sq/ft width 12' 4" x depth 5' 6"
Porch - Rear:
700 sq/ft width 21' 8" x depth 32' 4"
Study:
150 sq/ft width 15' x depth 10'
Utility Room:
24 sq/ft width 7' 6" x depth 3' 4"
Walk-In Closet:
32 sq/ft width 6' 5" x depth 5'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
| PDF Set
: $1140.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| 5 Copy Set
: $1230.00 |
5 printed plan sets mailed to you. |
| 8 Copy Set
: $1280.00 |
8 printed plan sets mailed to you. |
| Reproducible Set
: $1300.00 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
| CAD Set
: $2195.00 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Foundation
| Crawlspace: $0.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
| Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
| Basement: $150.00 |
Ideal for level lot, lower level of home partially or fully underground. |
Framing
| Wood 2x4: $0.00 |
Wood 2x4 |
| Wood 2x6: $150.00 |
Wood 2x6 |
Additional Options
| Right-Reading Reverse
: $350.00 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
| Additional Construction Sets
: $50.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design
: $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide
: $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design
: $100.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
| Mirror Reversed Sets
: $50.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
