Here's a standout new plan with a beautiful façade and thoughtful layout details. For example, a wall of glass in back lets lots of light into the great room and breakfast nook, with the fireplace moved to a side wall to keep the view clear. The master suite resides on this level, a good choice for aging in place. Growing families can opt to finish the fourth and fifth bedrooms upstairs. Extra storage in the garage is a welcome touch.
Full Specs & Features
Depth : 66' 6"
Height : 26'
Width : 61' 6"
Basement Unfinished: 1996 sq/ft
Bonus: 559 sq/ft
First Floor: 1996 sq/ft
Garage: 537 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Primary Pitch : 9:12
Roof Framing : Conventional
Roof Type : Asphalt
Secondary Pitch : 12:12
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Formal Dining Room
Formal Living Room / Parlor
Main Floor Master Bedroom
Walk In Closet
Kitchenette Wet Bar
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Covered Front Porch
Covered Rear Porch
width 11' x depth 12'
width 12' x depth 11'
width 12' 4" x depth 12' 6"
width 12' x depth 12' 6"
width 11' x depth 10'
width 13' x depth 11'
width 16' 4" x depth 16'
width 13' x depth 12' 6"
width 12' x depth 17'
width 13' x depth 11'
Porch - Rear:
188 sq/ft width 17' x depth 12'
