This fantasy begins as soon as you step from the porch into the two-story vaulted foyer. To the right sits the columned elegance of the formal dining room and to the left a personal library awaits. Steps away, the entrance to the master suite beckons with promises of a sitting area, morning kitchen, L-shaped walk-in closet, garden tub, separate shower, and dual vanities. The three family bedrooms upstairs each have a full bath and closet space. In addition to the bedrooms, the option of a game room/billiards room provides plenty of space for casual entertainment. A three-car garage completes this plan.
161 sq/ft width 12' 4" x depth 13' 1"
339 sq/ft width 23' 5" x depth 14' 6"
172 sq/ft width 11' 9" x depth 14' 8"
Bonus Room/Flex Space/Billiards:
width 22' 9" x depth 36' 10"
162 sq/ft width 13' 11" x depth 11' 8"
219 sq/ft width 12' 9" x depth 17' 3"
235 sq/ft width 13' 11" x depth 16' 11"
731 sq/ft width 33' 9" x depth 21' 8"
321 sq/ft width 22' 7" x depth 14' 3"
72 sq/ft width 7' 6" x depth 9' 5"
272 sq/ft width 13' 11" x depth 16' 11"
253 sq/ft width 17' 7" x depth 14' 5"
252 sq/ft width 14' x depth 18'
289 sq/ft width 14' 11" x depth 19' 5"
Master Sitting Room:
width 8' x depth 14' 9"
Master Walk-In Closet:
176 sq/ft width 7' x depth 16'
This designer charges a non-refundable $95.00 fee to review plan changes and prepare an estimate for your modifications. Please call if you would like to order a Plan Modification quote for this plan. All plans are drawn at ¼” scale or larger and include : Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas. Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements. Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches. Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing. Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required. » See important information before purchasing.
