PLAN 1066-42

Photographs may show modified designs.

Save
  • Jump to:
  • All (5)
  • Floor plans (2)
Questions? Get Personalized Help

Key Specs


Plan Sq Ft

4235
sq ft

Plan Bedrooms

5
Beds

Plan Bathrooms

4.5
Baths

Plan Floors

2
Floors

Plan Garages

2
Garages

Select Plan Set Options

What's included?

Additional options

Dropdown arrow

Right-Reading Reverse
$250.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Audio Video Design
$165.00
Receive an overlay sheet with suggested placement of audio and video components.
Comprehensive Material List
$395.00
A complete list of building supplies needed to construct the infrastructure of your new house, plus an overlay of materials shown directly on your PDF (foundation to rooftop with interior and exterior materials), and a detailed, itemized door and window schedule showing all sizes and types. Please allow 5-7 Business Days for completion. Note, the Comprehensive list is only available with a PDF purchase. The Comprehensive list can be ordered no matter what additional plan options you have selected.
Construction Guide
$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design
$165.00
Receive an overlay sheet with suggested placement of lighting fixtures.
Mirror Reversed Sets
$350.00
Printed sets showing plan in reverse, text and dimensions will be backwards.
Subtotal
$2117.00
Best Price Guaranteed*

Also order by phone: 1-877-222-1762

Questions about building your home?
Get Personalized Help
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-877-222-1762
Hours:
Ready for Your Call 7 Days a Week
Every Day 7 am - 8:30 pm Eastern

See our Terms & Conditions and Privacy Policy.


Wow!
Cost to Build Reports
are Only $4.99
with Code CTB2025 (limit 1)
This report will provide you cost estimates based on location and building materials.

Residential Construction Guide

Learn Building Basics

This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.

PLAN 1066-42

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.

Modify This Plan

Plan Description


Large bedrooms give everyone plenty of elbow room in this modern design, while a guest suite invites a grandparent or friend to stay on the main level. Storage abounds throughout the home, with a mudroom, big kitchen pantry, and a huge walk-in closet for the master suite. A bonus room can become a playroom or office.

Full Specs & Features


Dimension

Depth : 57'

Height : 29' 9"

Width : 63'

Area

Garage : 480 sq/ft

Main Floor : 2192 sq/ft

Patios : 250 sq/ft

Upper Floor : 2043 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Garage Ceiling : 11'

Main Ceiling : 10'

Upper Ceiling Ft : 9'

Roof

Primary Pitch : 10/12

Roof Framing : Wood

Roof Type : Trusses

Secondary Pitch : 6/12

Exterior Wall Framing

Exterior Wall Finish : Siding

Framing : Wood

Insulation : R21

Kitchen Features

Kitchen Island

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Family Room Keeping Room

Mud Room

Garage Features

Front Entry Garage

Outdoor Spaces

Covered Rear Porch

More

Jack & Jill Bath

What's Included In This Plan Set


All plans are drawn at ¼” scale or larger and include :

  • Cover Sheet: 3D Rendering and Project Information.
  • General Foundation notes (Builder and engineer to provide foundation specs based on lot and local code).
  • Floor Plans (lower, main, upper, etc.) showing all doors and windows.
  • Elevations from all four sides showing material callouts.
  • Wall framing and sectional detail sheets.
  • Building Cross Sections showing stair and ceiling height details.
  • Window and Door schedule.
  • Overhead roof plan showing peaks, valleys, and pitch.
  • Foundation Plan showing perimeter and footing details.
  • Misc. notes and details.
  • *Please note that any structural engineering sheets included with this plan set are for reference only.

» See important information before purchasing.
