Plan Description

Modern style single-family home with closed floor plan and two garages

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Floor Plan - Upper Floor

Reverse

Floor Plan - Lower Floor

Reverse

Full Specs & Features

Dimension

Depth : 48' 4"

Height : 36' 4"

Width : 83' 4"

Area

Garage : 437 sq/ft

Lower Floor : 440 sq/ft

Main Floor : 2054 sq/ft

Porch : 44 sq/ft

Storage : 92 sq/ft

Upper Floor : 1135 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Ceiling Details : Upper floor ceiling is vaulted, and the family room on the main floor has 14 ft ceilings

Garage Ceiling : 9'

Main Ceiling : 10'

Roof

Primary Pitch : 1.5/12

Roof Framing : Raftors

Roof Load : 25

Roof Type : Shed

Secondary Pitch : 2/12

Exterior Wall Framing

Exterior Wall Finish : Siding and Panels

Framing : 2X6

Insulation : R21

Bedroom Features

Lower Level Bedrooms

Upstairs Master Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Eating Bar

Kitchen Island

Kitchenette Wet Bar

Additional Room Features

Den Office Study Computer

Great Room Living Room

Upstairs Laundry

Wet Bar

Wine Cellar

Garage Features

Front Entry Garage

Garage Under

Side Entry Garage

Tandem Garage

Elevator
