PLAN 429-340
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 76' 9"
Height : 31' 6"
Width : 59' 9"
Area
First Floor: 2492 sq/ft height 10'
Second Floor: 798 sq/ft height 10'
Roof
Primary Pitch : 10:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Butler's Pantry
Kitchen Island
Additional Room Features
Great Room Living Room
Main Floor Laundry
Open Floor Plan
Unfinished Future Space
Outdoor Spaces
Covered Rear Porch
More
Jack & Jill Bath
Rooms
Bathroom 2:
75 sq/ft width 11' 3" x depth 6' 9"
Bathroom 3:
47 sq/ft width 9' x depth 5' 3"
Bedroom 2:
175 sq/ft width 13' 9" x depth 12' 9"
Bedroom 2 Closet:
18 sq/ft width 4' 6" x depth 4'
Bedroom 3:
174 sq/ft width 14' 3" x depth 12' 3"
Bedroom 3 Closet:
32 sq/ft width 5' x depth 6' 6"
Bonus Room - Finished:
404 sq/ft width 25' 3" x depth 16'
Breakfast Room:
144 sq/ft width 12' x depth 12'
Butler's Pantry:
34 sq/ft width 6' x depth 5' 9"
Coat Closet:
6 sq/ft width 2' 3" x depth 2' 9"
Covered Porch:
190 sq/ft width 19' x depth 10'
Dining Room:
168 sq/ft width 12' x depth 14'
Family Room:
508 sq/ft width 19' x depth 26' 9"
Foyer:
74 sq/ft width 8' 9" x depth 8' 6"
Garage:
675 sq/ft width 25' x depth 27'
Kitchen:
288 sq/ft width 18' x depth 16'
Kitchen Island:
16 sq/ft width 5' 6" x depth 3'
Laundry Room:
84 sq/ft width 7' 6" x depth 11' 3"
Linen Closet:
5 sq/ft width 2' 3" x depth 2' 3"
Master Bathroom:
188 sq/ft width 14' 3" x depth 13' 3"
Master Bedroom:
286 sq/ft width 14' 6" x depth 19' 9"
Master Closet:
125 sq/ft width 16' 3" x depth 7' 9"
Master Sitting Room:
60 sq/ft width 10' x depth 6'
Pantry:
9 sq/ft width 4' 6" x depth 2'
Study:
156 sq/ft width 13' x depth 12'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$900.00
$1000.00
$1250.00
$1250.00
$800.00
Foundation
$0.00
$150.00
$150.00
Framing
$0.00
Additional Options
$65.00
$100.00
$39.00
$200.00
$85.00
