Plan Description
This cottage garage sports siding and both a porch and upper-level deck. A two-car garage completes the first level while a spacious 773-square-foot apartment rounds out the second level. A large living and dining space enjoys a skylight and access to the deck. The U-shaped kitchen features all the amenities for small-scale living. A full bath and a bedroom with wall closet and bumped-out bay window finish up the apartment.
Floor Plans
Floor Plan - Main Floor
Floor Plan - Upper Floor
Full Specs & Features
Dimension
Depth : 31' 4"
Height : 29'
Width : 28'
Area
First Floor: 778 sq/ft height 8'
Second Floor: 773 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : 2 x 6
Bedroom Features
Formal Dining Room
Formal Living Room / Parlor
Outdoor Spaces
Covered Front Porch
Rooms
Dining Room:
315 sq/ft width 26' 4" x depth 12'
Garage:
675 sq/ft width 25' x depth 27'
Hall:
12 sq/ft width 3' 6" x depth 3' 6"
Hall Bathroom:
36 sq/ft width 5' x depth 7' 4"
Hall Closet:
8 sq/ft width 4' x depth 2'
Kitchen:
88 sq/ft width 8' x depth 11'
Master Bedroom:
143 sq/ft width 11' x depth 13'
Master Closet:
14 sq/ft width 2' x depth 7' 4"
Porch - Front:
5 sq/ft width 1' 4" x depth 4'
Porch - Rear:
71 sq/ft width 5' x depth 14' 4"
Slab Foundation:
728 sq/ft width 26' x depth 28'
What's Included In This Plan Set
- Foundation Plan(s): This page shows all necessary notations and dimensions including footings, support columns, walls, and excavated/unexcavated areas.
- Floor Plan(s): Detailed plans for each level showing room dimensions, wall partitions, windows and doors, fixture locations, and ceiling treatments.
- Exterior Elevations: Views of the home from all four sides showing exterior materials, roof slope, ridge heights, siding and trim notes.
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
- Construction Notes and Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
