Plan Description

A sundeck makes this design popular, and it is even more enhanced by views through an expansive glass wall in the living and dining rooms. These rooms are warmed by a woodstove and Enjoy vaulted ceilings as well. The kitchen is also vaulted and has a prep island and breakfast bar. Behind the kitchen is a laundry room with side-deck access. Two bedrooms and a full bath are Found on the first floor. A skylit staircase leads up to the master suite and its walk-in closet and private bath on the second floor.

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Floor Plan - Upper Floor

Reverse

Full Specs & Features

Dimension

Depth : 39' 9"

Height : 27'

Width : 28'

Area

First Floor: 1061 sq/ft height 8'

Second Floor: 482 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 12:12

Roof Framing : Conventional

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Siding

Framing : Wood - 2x6

Bedroom Features

Fireplace

Formal Dining Room

Formal Living Room / Parlor

Walk In Closet

Kitchen Features

Kitchenette Wet Bar

Additional Room Features

Loft

Main Floor Laundry

Outdoor Spaces

Balcony

Covered Front Porch

Rooms

3rd BR Closet:

9 sq/ft width 2' x depth 4' 6"

Bedroom 2:

146 sq/ft width 11' x depth 13' 4"

Bedroom 2 Closet:

15 sq/ft width 5' 4" x depth 3'

Bedroom 3:

110 sq/ft width 11' x depth 10'

Bedroom 3 Closet:

15 sq/ft width 5' 4" x depth 3'

Crawlspace Foundation:

1113 sq/ft width 39' 9" x depth 28'

Deck:

336 sq/ft width 12' x depth 28'

Dining Room:

110 sq/ft width 8' 2" x depth 13' 6"

Hall Bathroom:

42 sq/ft width 5' x depth 8' 7"

Hall Closet:

10 sq/ft width 5' 4" x depth 2'

Kitchen:

90 sq/ft width 9' x depth 10'

Living Room:

195 sq/ft width 14' 6" x depth 13' 6"

Master Bathroom:

66 sq/ft width 5' x depth 13' 4"

Master Bedroom:

213 sq/ft width 10' 10" x depth 19' 8"

Master Closet:

49 sq/ft width 5' 5" x depth 9' 2"

Utility Room:

63 sq/ft width 6' 4" x depth 10'
