PLAN 70-1489

Home > Style > Contemporary

Key Specs

1484
sq ft

2
Beds

2
Baths

1
Floors

3
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.

Modify This Plan

Plan Description

Get bold style, even on a small budget. This modern home plan gives you an open layout with 1,484 square feet, two bedrooms (one of them the master suite, complete with two sinks and a big shower) and tons of storage. A three-car garage holds cars and more.

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Full Specs & Features

Dimension

Depth : 50'

Height : 17' 4"

Width : 50'

Area

Garage : 725 sq/ft

Main Floor : 1484 sq/ft

Porch : 164 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Ceiling Details : 9' 1" to 10' 1" step ceiling in Foyer; 9' 1" to 9' 7" step ceiling in Master Bedroom

Main Ceiling : 9' 1"

Roof

Primary Pitch : 4:12

Roof Framing : Truss

Roof Load : 47 psf

Roof Type : Shingle

Secondary Pitch : 4:12

Exterior Wall Framing

Exterior Wall Finish : Stone/Siding

Framing : 2 x 6

Bedroom Features

Main Floor Bedrooms

Main Floor Master Bedroom

Walk In Closet

Kitchen Features

Walk In Pantry Cabinet Pantry

Additional Room Features

Great Room Living Room

Main Floor Laundry

Storage Area

Garage Features

Front Entry Garage

Lot Characteristics

Suited For Narrow Lot

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

Grill Deck Sundeck

Empty Nester

Rooms

Bedroom 2:

width 13' x depth 11'

Covered Front Porch:

width 6' x depth 8' 4"

Covered Rear Porch:

width 7' 8" x depth 15' 4"

Deck:

width 21' x depth 8'

Dining Room:

width 13' 4" x depth 12' 4"

Foyer:

width 6' 4" x depth 15' 8"

Garage:

width 29' 4" x depth 21' 4"

Great Room:

width 14' 8" x depth 19' 4"

Hall Bath :

width 9' x depth 5'

Kitchen:

width 13' 4" x depth 13'

Laundry:

width 5' 8" x depth 10' 8"

Master Bath:

width 13' x depth 6'

Master Bedroom:

width 13' x depth 14'

Pantry:

width 4' 8" x depth 4' 8"

Storage:

width 7' 4" x depth 10' 8"

What's Included In This Plan Set

See a sample plan set

Plans are typically drawn to ¼” scale and include:

Cover Sheet: Cover sheet with front rendering
Foundation Plan(s): Foundation plans at 1/4" = 1' scale
Floor Plan(s): Floor plans at 1/4" = 1' scale
Exterior Elevations: Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
Building Section(s): Building sections and details as required to construct the individual design
Electrical Plan(s): Schematic electrical plans with suggested switch, outlet, and light fixture locations
Kitchen Cabinet Elevation(s): Interior elevation of cabinets at 1/4" = 1' scale
Construction Notes / Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
Specification(s): General specification design notes

Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.

Questions? Call 1-877-222-1762
