PLAN 515-16

Home > Style > Craftsman

Key Specs

924
sq ft

0
Beds

0
Baths

1
Floors

4
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.

Modify This Plan

Plan Description

4 Car Detached Garage plan with lots of room for hobbies and toys,

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Full Specs & Features

Dimension

Depth : 22'

Height : 19'

Width : 42'

Area

Garage : 924 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 9'

Roof

Primary Pitch : 6:12

Roof Framing : Truss

Exterior Wall Framing

Framing : 2x4

Garage Features

Front Entry Garage

Wheelchair Adaptable

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: This page shows all necessary notations and dimensions including support columns, walls, and excavated/unexcavated areas.
Exterior Elevations: Views of the home from all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans for each level showing room dimensions, wall partitions, windows and doors, etc.
Cross Section: A slice of the home from roof to foundation, showing important details like stairs and wall construction.
Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
Construction Notes and Details: Shows the builder how things come together, like walls, the chimney, insulation, and more.

Questions? Call 1-877-222-1762

Plan Set

PDF Set:
$420.75

PDF plan sets are best for fast electronic delivery and inexpensive local printing.

Reproducible Set:
$505.75

For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.

5 Copy Set:
$786.25

5 printed plan sets mailed to you.

Foundation

Slab:
$0.00

Ideal for level lot, single layer concrete poured directly on grade.

Additional Options

Right-Reading Reverse:
$127.50

Choose this option to reverse your plans and to have the text and dimensions readable.

Additional Construction Sets:
$42.50

Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Audio Video Design:
$140.25

Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide:
$33.15

Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design:
$140.25

Receive an overlay sheet with suggested placement of lighting fixtures.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
