PLAN 942-16
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 74' 2"
Height : 41' 9"
Width : 92' 2"
Area
Basement Living: 1986 sq/ft
Basement Unfinished: 691 sq/ft
First Floor: 2725 sq/ft
Garage: 1084 sq/ft
Second Floor: 1165 sq/ft
Roof
Primary Pitch : 5:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Stone/Stucco
Framing : Wood - 2x6 Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Guest Suite
Main Floor Master Bedroom
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Butler's Pantry
Kitchen Island
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Exercise Room
Family Room Keeping Room
Great Room Living Room
Hobby Rec Room Game Room
Loft
Main Floor Laundry
Master Sitting Area
Media Room
Mud Room
Open Floor Plan
Storage Area
Upstairs Laundry
Vaulted / Cathedral Ceilings
Wine Cellar
Garage Features
Front Entry Garage
Outdoor Spaces
Balcony
Courtyard
Covered Front Porch
Covered Rear Porch
Deck
Grill Deck Sundeck
Outdoor Kitchen Grill
Rooms
Bedroom 2:
width 15' 6" x depth 12' 6"
Bedroom 3:
width 12' x depth 13'
Bedroom 4:
width 12' 6" x depth 13'
Bedroom 5:
width 11' 6" x depth 12'
Bedroom 5 Living Area:
width 11' x depth 12'
Breakfast Nook:
width 10' x depth 10'
Dining Room:
width 10' 6" x depth 14'
Exercise Room:
width 22' x depth 17'
Family Room:
width 16' x depth 21'
Foyer:
width 9' 6" x depth 12'
Game Room:
width 10' x depth 13'
Garage:
1084 sq/ft width 41' x depth 26'
Great Room:
width 16' x depth 21'
Home Office:
width 11' 6" x depth 12'
Kitchen:
width 16' x depth 17' 6"
Loft:
width 13' x depth 8'
Master Bedroom:
width 17' x depth 20'
Mechanical:
width 23' x depth 7' 6"
Storage/Future Development:
width 22' 6" x depth 18' 6"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$4400.00
$5050.00
$2185.00
Foundation
$0.00
Framing
$0.00
Additional Options
$935.00
$165.00
$39.00
$165.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
