This courtyard design allows for intimate poolside gatherings in complete privacy. Varied ceiling designs create more excitement as you enter through mahogany doors, passing the paved courtyard lavishly appointed with tropical flowers and a pool with a waterfall and spa. The generous master suite features sculptured ceilings, while the master bath is sumptuously appointed with grand arches over the spa tub. Two bedrooms upstairs access a private balcony terrace. A privately accessed guest suite/home office rounds out this award-winning design. Note the large summer kitchen near the garage, as well as the intimate sunken powder room tucked under the staircase.
173 sq/ft width 13' 4" x depth 13'
143 sq/ft width 13' x depth 11'
78 sq/ft width 8' x depth 9' 10"
199 sq/ft width 15' x depth 13' 4"
328 sq/ft width 19' 4" x depth 17'
240 sq/ft width 16' x depth 15'
65 sq/ft width 7' 10" x depth 8' 4"
207 sq/ft width 14' 1" x depth 14' 9"
291 sq/ft width 17' 8" x depth 16' 6"
408 sq/ft width 15' 4" x depth 26' 8"
