Key Specs
3120
sq ft
5
Beds
2.5
Baths
2
Floors
2
Garages
Phone: 1-877-222-1762
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 943-12
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 52'
Height : 31' 6"
Width : 40'
Area
First Floor: 1471 sq/ft height 9'
Garage: 397 sq/ft height 9'
Second Floor: 1649 sq/ft height 9'
Roof
Primary Pitch : 7:12
Roof Framing : Combination Truss/Conventional
Roof Type : Composition
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : Wood - 2x6
Bedroom Features
Formal Dining Room
Formal Living Room / Parlor
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Additional Room Features
Family Room Keeping Room
Rooms
Bedroom 1:
224 sq/ft width 16' x depth 14'
Bedroom 2:
146 sq/ft width 11' x depth 13' 4"
Bedroom 3:
139 sq/ft width 11' x depth 12' 8"
Bedroom 4:
150 sq/ft width 11' x depth 13' 8"
Dining Room:
144 sq/ft width 12' x depth 12'
Family Room:
339 sq/ft width 18' 2" x depth 18' 8"
Living Room:
156 sq/ft width 12' x depth 13'
Master Bedroom:
265 sq/ft width 15' x depth 17' 8"
Nook:
162 sq/ft width 12' 6" x depth 13'
What's Included In This Plan Set
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
