Plan Description


Versatility, that is the action word for this Contemporary styled, narrow lot house plan. It is versatile in form and function. This is most evident by the addition of a side entrance with its own courtyard. This simple feature makes this plan ideal for multi-generational house holds. Continuing with that theme, the den / media room can easily be turned into a third guest bedroom, which will give this home plenty of places to find privacy while incorporating an open floor plan. The great room, which is an ideal place for family and friends to gather, is flanked on the left by the large kitchen. Thanks to the large walk-in pantry, you’ll always have the supplies you need no matter the occasion. The wet bar is centrally located, ideal for family gatherings. But why be stuck inside when you have a large veranda to enjoy? This space is the perfect gateway to your swimming pool or backyard. And there is no need to head back inside when you get hungry. Just a few steps from the veranda is the Solana and its outdoor kitchen. You will find yourself using your built-in grill more often than the indoor kitchen. After all that time with family and friends, you’re going to need some place to relax and refresh. Your master suite has direct access to the backyard by the way of a sliding glass door. From there you can take a walk past your large His & Hers walk-in closets to your master bath. There you will have the option to take a long luxurious bath in your soaking tub, or a quick wash-up in your walk-in shower. The Sawgrass home is the ideal place for an expanding or extended family to call home. The versatility and livability designed into this home plan makes it perfect for today and tomorrow. **This plan cannot be built in Lee/Collier County, FL. **

Full Specs & Features


Dimension

Depth : 107' 4"

Height : 23' 3"

Width : 43' 4"

Area

Garage : 568 sq/ft

Main Floor : 2415 sq/ft

Patios : 415 sq/ft

Porch : 60 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Garage Ceiling : 10'

Main Ceiling : 10'

Roof

Primary Pitch : 6/12

Exterior Wall Framing

Exterior Wall Finish : Stucco

Framing : Block

Bedroom Features

Main Floor Bedrooms

Main Floor Master Bedroom

Walk In Closet

Kitchen Features

Eating Bar

Kitchen Island

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Great Room Living Room

Hobby Rec Room Game Room

Main Floor Laundry

Play Flex Room

Wet Bar

Garage Features

Side Entry Garage

Lot Characteristics

Suited For Narrow Lot

Outdoor Spaces

Covered Rear Porch

Outdoor Kitchen Grill

More

Additional Half Bath

What's Included In This Plan Set


This designer charges $75.00 to review plan changes and prepare an estimate for your modifications. This fee can be applied to your plan purchase once you move forward with the modifications. Please give us a call if you would like to order a Plan Modification quote.

Some of this designer's ready-made house plans are not for sale in Lee and Collier, and Charlotte Counties of Florida. Please give us a call if you are building in one of these counties.

Cover Sheet, Index & Site Plan: The cover sheet features an elevation of the exterior of the house that shows approximately how the home will look when built. The index lists the order of the drawings included, with page numbers for easy reference. The site plan is a scaled footprint of the house to help determine how the home will be placed on the building site.

Wall Sections & Notes: This section shows section cuts of the exterior wall from the roof down through the foundation. These wall sections specify the home’s construction and building materials. They also show the number of stories, type of foundation and the construction of the walls. Roofing materials, insulation, floor framing, wall finishes and elevation heights are all shown and referenced.

Typical Details & Notes: This section addresses all the facets and typical details you will want to include in your home, with the exception of local building code requirements. Architectural and structural elements are detailed, including: window and door components, railings, balusters, wood stairs and headers, interior walls, interior partitions, concrete steps and footings (if applicable).

Foundation layout Plan: This sheet provides a fully dimensioned and noted foundation layout, including references to footings, pads, and support walls. For plans with a basement, additional walls and columns may be shown. Basement plans come with a floor framing layout which may be included in this section or the floor framing section, depending on the plan. *Actual structural information should be obtained by a locally licensed engineer for your specific site location.

Detailed Floor Plan: This section provides detailed floor plan drawings and descriptions of all the elements that will be included on each floor of the home. The home’s exterior footprint, openings and interior rooms are carefully dimensioned. Important features are noted including built-ins, niches and appliances. All doors and windows are identified. Typically this section also includes the square footage information.

Reflected Ceiling Plan: This designer's most distinguishable features is the highly detailed ceiling treatments. This section shows ceiling heights and treatments. It also shows the details, profiles and finishes of the ceiling treatments. Arches and soffits are also specified in this section.

Floor Framing Plans: Homes with a basement or crawl space will have a floor framing plan for the first floor. Multi-story homes will have floor framing plans for upper floors as well. The floor framing plans provide structural information such as the joist location, spacing and direction, as well as the floor heights and stair openings.

Roof Layout: The overall layout and necessary details for roof design are provided in this section. If trusses are used, we suggest using a local truss manufacturer to design your roof trusses to comply with your local codes and regulations.

Exterior Elevations: Exterior elevations are drawings that show how the finished home will approximately look. In this section, elevations of the front, rear and left and right sides of the home are shown. Exterior materials, details and heights are noted on these drawings.

Building Section & Details: This section will illustrate the important changes in the floor, ceiling and roof heights or the relationship of different floors to one another. Interior elements of rooms and areas, such as columns, arches, headers and soffits, are also discernible and easier to visualize in a cross section.

Interior Elevations: These interior elevations show the specific details and design of the kitchen, bathrooms, utility rooms, fireplaces, bookcases, built-in units and other special interior features. The interior elevations vary based on the complexity of the home.

Electrical Plan: This section shows an electrical plan that will enhance functionality and highlight the unique architectural features of the home.
