PLAN 51-1137
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 73' 2"
Height : 29'
Width : 71'
Area
Basement : 2287 sq/ft
Bonus : 535 sq/ft
Garage : 636 sq/ft
Main Floor : 2287 sq/ft
Ceiling
Bonus Ceiling : 8'
Garage Ceiling : 10' 6"
Lower Ceiling : 9'
Main Ceiling : 9'
Roof
Primary Pitch : 14:12
Roof Framing : trusses
Exterior Wall Framing
Exterior Wall Finish : siding
Framing : 2 x 6
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Mud Room
Play Flex Room
Unfinished Future Space
Garage Features
Side Entry Garage
Entryway
Friend S Entry
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
What's Included In This Plan Set
- Foundation Plan(s): This page shows all necessary notations and dimensions including footings, support columns, walls, and excavated/unexcavated areas.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements. Drawn to 1/4" and 1/8" scale.
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
- Construction Notes / Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
- Other Note(s): This plan will not contain an electrical layout.
Plan Set
$2050.00
$2250.00
$2350.00
$2350.00
$2700.00
Foundation
$0.00
$400.00
$400.00
$400.00
$400.00
Framing
$0.00
$250.00
Additional Options
$250.00
$400.00
$75.00
$165.00
$39.00
$300.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
