PLAN 20-2315

Architectural House Design - Cottage Exterior - Rear Elevation Plan #20-2315

Architectural House Design - Right Side Elevation

Architectural House Design - Left Side Elevation

Key Specs

2232
sq ft

4
Beds

3
Baths

2
Floors

2
Garages

Select Plan Set Options

What's included?

	Right-Reading Reverse $195.00 Choose this option to reverse your plans and to have the text and dimensions readable.
	Additional Construction Sets $45.00/each Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
	Audio Video Design $100.00 Receive an overlay sheet with suggested placement of audio and video components.
	Construction Guide $39.00 Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
	Lighting Design $100.00 Receive an overlay sheet with suggested placement of lighting fixtures.
	Mirror Reversed Sets $45.00 Printed sets showing plan in reverse, text and dimensions will be backwards.
	Unlimited Use License $500.00 Unlimited Use License.

Subtotal

$1055.00

Best Price Guaranteed*

Also order by phone: 1-877-222-1762

Cost to Build Reports Only $9.99 for a Limited Time! Use Code CTB2021

This report will provide you cost estimates based on location and building materials.

Get Cost-To-Build Report

Or order by phone: 1-877-222-1762

Questions?

When do you want to start construction?

Do you have a lot?

Are you working with a builder?

Where do you plan on building?

Please enter your question(s)

Send me your Newsletter, too!

We do our best to get back to you within 24 - 48 business hours.

Need an answer faster? Call now...
Phone: 1-877-222-1762

Hours: Mon-Fri, 9AM - 8:30PM (EST)

See our Terms & Conditions and Privacy Policy.

PLAN 20-2315

Key Specs

2232
sq ft

4
Beds

3
Baths

2
Floors

2
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.

Modify This Plan

Plan Description

An extra master suite on the main level opens up many options. For example, an elderly relative will appreciate the private bathroom and easy access to the suite. Alternatively, visitors can spread out and relax here. A pocket office and drop zone add contemporary storage. Meanwhile, the primary master suite treats owners to double sinks and a big shower. Two more bedrooms upstairs include spacious closets. The home’s modest width and front-facing garage suit it for a smallish lot.

Floor Plans

Floor Plan - Main Floor

Reverse

Architectural House Design - Cottage Floor Plan - Main Floor Plan #20-2315

BUILDER Advantage Program

PRO BUILDERS:

Join the club and save 5% on your first order plus exclusive discounts and more.

JOIN FOR FREE

Click to Get Your Trend Report

Floor Plan - Upper Floor

Reverse

Architectural House Design - Cottage Floor Plan - Upper Floor Plan #20-2315

Full Specs & Features

Dimension

Depth : 54'
Height : 26' 9"
Width : 44'

Area

Garage : 512 sq/ft
Main Floor : 1676 sq/ft
Porch : 1128 sq/ft
Upper Floor : 556 sq/ft

*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Ceiling Details : Sloped ceiling in Great Room; Kitchen and Dining Room; 9' to 10' step ceiling in Master Suite
Main Ceiling : 9'
Upper Ceiling Ft : 8'

Roof

Primary Pitch : 7:12
Roof Framing : Conventional
Roof Type : Asphalt Shingle
Secondary Pitch : 7:12

Exterior Wall Framing

Exterior Wall Finish : Stone/Siding
Framing : 2 x 6

Bedroom Features

Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Upstairs Bedrooms
Walk In Closet

Kitchen Features

Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Mud Room

Garage Features

Front Entry Garage

Lot Characteristics

Suited For Narrow Lot

Outdoor Spaces

Covered Front Porch

Economical To Build
Empty Nester

What's Included In This Plan Set

See a sample plan set

Cover Page: Front elevation and informative reference sections including: general notes and design criteria
Elevations: Drafted at 1/4" scale for the front and 1/8" scale for the rear and sides. All elevations are noted and an aerial view of the roof is provided, showing all hips, valleys and ridges.
Foundation: Drafted at 1/4" scale. Poured or block basement or slab foundations are standard. Shows the HVAC equipment, structural information, steel beam and pole locations and the direction and spacing of the floor system above. Alternate foundations are available for a fee.
Main Level Floor Plan: 1/4" scale. Fully dimensioned from stud to stud for ease of framing. 2x4 walls are standard. The detailed drawings include such things as structural header locations, framing layout and kitchen layout.
Second Level Floor Plan: 1/4" scale. Dimensioned from stud to stud and drafted to the same degree of detail as the main level floor plan.
Elevations: Useful for the cabinet and bidding process, this page shows all kitchen and bathroom cabinets as well as any other cabinet elevations.
Electrical and Sections: Illustrated on a separate page for clarity, the electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall and stair sections are provided to further explain construction of these areas.

» See important information before purchasing.

Questions? Call 1-877-222-1762

Plan Set

PDF Set : $1055.00	PDF plan sets are best for fast electronic delivery and inexpensive local printing.
CAD Set : $1830.00	For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Study Set : $685.00	One electronic set for bidding purposes only. Not a legal building set for construction.

Foundation

Basement: $0.00	Ideal for level lot, lower level of home partially or fully underground.
Crawlspace: $195.00	Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.
Slab: $195.00	Ideal for level lot, single layer concrete poured directly on grade.

Additional Options

Right-Reading Reverse : $195.00	Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Construction Sets : $45.00	Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design : $100.00	Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide : $39.00	Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design : $100.00	Receive an overlay sheet with suggested placement of lighting fixtures.
Mirror Reversed Sets : $45.00	A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.
Unlimited Use License : $500.00	Unlimited Use License.

*Alternate Foundations may take time to prepare.

*Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
