3rd BR Closet:
10 sq/ft width 5' x depth 2'
Bathroom 2:
45 sq/ft width 5' x depth 9'
Bedroom 2:
143 sq/ft width 13' x depth 11'
Bedroom 2 Closet:
14 sq/ft width 7' x depth 2'
Bedroom 3:
156 sq/ft width 13' x depth 12'
Bedroom 3 Closet:
14 sq/ft width 7' x depth 2'
Breakfast Room:
81 sq/ft width 9' x depth 9'
Dining Room:
144 sq/ft width 12' x depth 12'
Foyer:
45 sq/ft width 9' x depth 5'
Garage:
460 sq/ft width 20' x depth 23'
Gathering Room:
425 sq/ft width 17' x depth 25'
Hall Closet:
180 sq/ft width 3' x depth 60'
Kitchen:
168 sq/ft width 12' x depth 14'
Master Bathroom:
228 sq/ft width 12' x depth 19'
Master Bedroom:
247 sq/ft width 13' x depth 19'
Master Closet:
36 sq/ft width 6' x depth 6'
Porch - Front:
120 sq/ft width 20' x depth 6'
Porch - Rear:
264 sq/ft width 44' x depth 6'
Powder Room:
28 sq/ft width 4' x depth 7'
Study:
72 sq/ft width 8' x depth 9'
Utility Room:
42 sq/ft width 7' x depth 6'
All plans are drawn at ¼” scale or larger and include :
5 Copy Set : $573.75 |
5 printed plan sets mailed to you. |
8 Copy Set : $658.75 |
8 printed plan sets mailed to you. |
Reproducible Set : $658.75 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
Single Set : $467.50 |
One printed set for bidding purposes only. Not a legal building set for construction. |
Crawlspace: $0.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
Additional Construction Sets : $42.50 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
Audio Video Design : $85.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
Construction Guide : $33.15 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
Lighting Design : $85.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
Material List : $42.50 |
A list of building supplies needed to construct the infrastructure of your new house. Please note materials lists will not reflect add-ons such as alternate foundation and framing options. |
Mirror Reversed Sets : $0.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
