PLAN 14-252
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 51'
Width : 56'
Area
First Floor: 1902 sq/ft height 8'
Ceiling
Ceiling Details : 10' ceiling in great room, kitchen, dining, and foyer. 10' step up ceiling in master.
Main Ceiling : 8'
Roof
Primary Pitch : 6:12
Roof Framing : stick
Secondary Pitch : 12:12
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : 2"x4"
Rooms
Bathroom 2:
54 sq/ft width 5' 10" x depth 9' 5"
Bedroom 2:
152 sq/ft width 12' x depth 12' 8"
Bedroom 2 Closet:
21 sq/ft width 8' 6" x depth 2' 6"
Bedroom 3:
146 sq/ft width 12' x depth 12' 2"
Bedroom 3 Closet:
25 sq/ft width 4' 4" x depth 5' 10"
Dining Room:
115 sq/ft width 10' 1" x depth 11' 6"
Foyer:
31 sq/ft width 7' x depth 4' 6"
Great Room:
323 sq/ft width 17' x depth 19'
Home Office:
138 sq/ft width 12' x depth 11' 6"
Kitchen:
152 sq/ft width 13' x depth 11' 9"
Laundry Room:
54 sq/ft width 5' 8" x depth 9' 8"
Master Bathroom:
72 sq/ft width 11' 2" x depth 6' 6"
Master Bedroom:
266 sq/ft width 14' x depth 19'
Master Closet:
81 sq/ft width 11' 6" x depth 7' 1"
Porch - Front:
147 sq/ft width 24' 6" x depth 6'
Porch - Rear:
55 sq/ft width 5' 6" x depth 10'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$625.00
$725.00
$725.00
$725.00
$510.00
Foundation
$0.00
Additional Options
$55.00
$55.00
$100.00
$39.00
$100.00
$45.00
$0.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
