PLAN 42-503

Key Specs


2069
sq ft

3
Beds

2
Baths

1
Floors

2
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.

Plan Description


This home features a proliferation of built-in amenities, with columns accenting the inside and outside of the house for exceptional grandeur. An open floor plan situates all of your needs--a formal dining room, recreation room, kitchen with breakfast nook and snack bar, laundry, patio, and split bedrooms, featuring an incredible master suite. Perks include crafted French doors, wood fireplace, covered patio in back and a partially covered porch at the front, unusually shaped rooms, and arched windows. This design also provides for a bonus attic or loft.

Floor Plans


Floor Plan - Main Floor Plan
Reverse
Save
Floor Plan - Upper Floor Plan
Reverse
Save
Floor Plan - Other Floor Plan
Reverse
Save

Full Specs & Features


Dimension
Depth : 68' 10"
Height : 24'
Width : 57' 8"
Area
Bonus: 304 sq/ft
First Floor: 2069 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 8:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Split Bedrooms
Kitchen Features
Breakfast Nook
Kitchenette Wet Bar
Additional Room Features
Hobby Rec Room Game Room
Main Floor Laundry
Open Floor Plan
Outdoor Spaces
Courtyard
Covered Front Porch
Rooms

3rd BR Closet:

26 sq/ft width 2' 8" x depth 10'

Bedroom 2:

132 sq/ft width 11' x depth 12'

Bedroom 2 Closet:

16 sq/ft width 2' x depth 8'

Bedroom 3:

147 sq/ft width 12' x depth 12' 4"

Bedroom 3 Closet:

16 sq/ft width 2' x depth 8'

Breakfast Room:

103 sq/ft width 10' x depth 10' 4"

Dining Room:

168 sq/ft width 12' x depth 14'

Garage:

399 sq/ft width 19' x depth 21'

Garage Storage:

63 sq/ft width 7' x depth 9'

Gathering Room:

362 sq/ft width 16' x depth 22' 8"

Hall Bathroom:

62 sq/ft width 7' 10" x depth 8'

Hall Closet:

5 sq/ft width 2' x depth 2' 8"

Kitchen:

149 sq/ft width 11' 6" x depth 13'

Master Bathroom:

126 sq/ft width 9' x depth 14'

Master Bedroom:

208 sq/ft width 13' x depth 16'

Master Closet:

90 sq/ft width 9' x depth 10'

Utility Room:

37 sq/ft width 5' 4" x depth 7'

What's Included In This Plan Set


See a sample plan set

All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
» See important information before purchasing.

Plan Set

5 Copy Set :
$795.00
5 printed plan sets mailed to you.
8 Copy Set :
$845.00
8 printed plan sets mailed to you.
PDF Set :
$895.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
Reproducible Set :
$995.00
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.
Single Set :
$700.00
One printed set for bidding purposes only. Not a legal building set for construction.
