PLAN 20-119

Key Specs


2040
sq ft

3
Beds

3
Baths

1
Floors

2
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.

Floor Plans


Floor Plan - Main Floor Plan
Reverse
Save
Floor Plan - Upper Floor Plan
Reverse
Save

Full Specs & Features


Dimension
Depth : 56'
Height : 28'
Width : 60'
Area
Bonus: 409 sq/ft
First Floor: 2040 sq/ft height 9'
Garage: 530 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 12:12
Roof Framing : Truss
Roof Type : Tile
Secondary Pitch : 12:12
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : 2"x4"
Bedroom Features
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
More
Jack & Jill Bath
Rooms

Bathroom 2:

23 sq/ft width 5' 4" x depth 4' 6"

Bathroom 3:

55 sq/ft width 5' x depth 11'

Bedroom 2:

124 sq/ft width 11' 4" x depth 11'

Bedroom 3:

156 sq/ft width 12' x depth 13'

Bonus Room - Unfinished:

449 sq/ft width 18' 4" x depth 24' 6"

Dining Room:

182 sq/ft width 11' 8" x depth 15' 8"

Foyer:

67 sq/ft width 9' x depth 7' 6"

Garage:

522 sq/ft width 21' 4" x depth 24' 6"

Kitchen:

157 sq/ft width 12' 4" x depth 12' 9"

Kitchen Island:

6 sq/ft width 2' x depth 3'

Living Room:

320 sq/ft width 16' x depth 20'

Master Bathroom:

145 sq/ft width 9' 6" x depth 15' 4"

Master Bedroom:

213 sq/ft width 13' 4" x depth 16'

Master Closet:

56 sq/ft width 11' 4" x depth 5'

Nook:

113 sq/ft width 10' x depth 11' 4"

Utility Room:

32 sq/ft width 5' 2" x depth 6' 4"

What's Included In This Plan Set


See a sample plan set
  • Cover Page: Each home plan features the front elevation and informative reference sections including general notes and design criteria.
  • Elevations: Drafted at ¼" scale for the front and 1/8" scale for the rear and sides. All elevations are detailed and an aerial view of the roof is provided, showing all hips, valleys, ridges and framing.
  • Foundations: Drafted at ¼" - 1' scale. This plan is designed as a slab foundation. Optional basement or crawl space foundations are available. Basement foundations may require additional engineering for steel beam sizes.
  • Main Level Floor Plan: Drafted at ¼" scale. 2" x 4" walls are standard. The detailed drawings include such things as ceiling treatments and header locations.
  • Second Level Floor Plan: Drafted at ¼" scale. Drafted to the same degree of detail as the main level floor plan.
  • Interior Elevations: Kitchen cabinet elevations are drawn.
  • Electrical and Sections: The electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall, stair, brick sections are provided to further explain construction of these areas.
» See important information before purchasing.

Plan Set

PDF Set :
$925.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
CAD Set :
$1175.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Foundation

Slab:
$0.00
Ideal for level lot, single layer concrete poured directly on grade.

Additional Options

Right-Reading Reverse :
$150.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Audio Video Design :
$100.00
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide :
$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design :
$100.00
Receive an overlay sheet with suggested placement of lighting fixtures.
Mirror Reversed Sets :
$0.00
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.
