PLAN 569-6
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 55'
Height : 18' 3"
Width : 46'
Area
First Floor: 1758 sq/ft height 9'
Garage: 480 sq/ft height 9'
Porch: 91 sq/ft
Roof
Primary Pitch : 4:12
Roof Framing : Truss
Roof Type : Composition
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : Wood - 2x6
Bedroom Features
Fireplace
Guest Suite
Walk In Closet
Kitchen Features
Kitchen Island
Kitchenette Wet Bar
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Open Floor Plan
Vaulted / Cathedral Ceilings
Outdoor Spaces
Courtyard
Rooms
Bedroom 3:
140 sq/ft width 11' 8" x depth 12'
Dining Room:
130 sq/ft width 13' x depth 10'
Garage:
458 sq/ft width 19' 6" x depth 23' 6"
Great Room:
304 sq/ft width 16' x depth 19'
Guest Bedroom:
137 sq/ft width 11' x depth 12' 6"
Kitchen:
117 sq/ft width 13' x depth 9'
Master Suite:
210 sq/ft width 13' x depth 16' 2"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$680.00
$1360.00
Foundation
$0.00
$0.00
Framing
$0.00
Additional Options
$140.25
$33.15
$140.25
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
