PLAN 17-2763
Key Specs
5723
sq ft
4
Beds
3.5
Baths
1
Floors
3
Garages
Cost to Build Reports Only $9.99 with Code CTB2021 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Phone: 1-877-222-1762
See our Terms & Conditions and Privacy Policy.
PLAN 17-2763
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Full Specs & Features
Height : 41'
Width : 73' 8"
First Floor: 2907 sq/ft height 9'
Porch: 543 sq/ft
Storage: 676 sq/ft
Roof Framing : Combination Truss/Conventional
Roof Type : Shingle
Framing : Wood - 2x4
Guest Suite
Main Floor Master Bedroom
Walk In Closet
Kitchenette Wet Bar
Great Room Living Room
Hobby Rec Room Game Room
Main Floor Laundry
Master Sitting Area
Media Room
Safe Room / Hidden Room
Sunroom
Covered Rear Porch
Deck
Grill Deck Sundeck
Screened Porch
Bedroom 2:
168 sq/ft width 14' x depth 12'
Bedroom 3:
135 sq/ft width 11' 4" x depth 12'
Bedroom 4:
127 sq/ft width 11' 4" x depth 11' 3"
Breakfast Room:
167 sq/ft width 11' 2" x depth 15'
Deck:
273 sq/ft width 28' 4" x depth 9' 8"
Dining Room:
159 sq/ft width 11' x depth 14' 6"
Foyer:
101 sq/ft width 7' x depth 14' 6"
Garage:
668 sq/ft width 28' 8" x depth 23' 4"
Garage Storage:
668 sq/ft width 28' 8" x depth 23' 4"
Great Room:
347 sq/ft width 18' x depth 19' 4"
Grilling Porch:
226 sq/ft width 28' 4" x depth 8'
Guest Bedroom:
192 sq/ft width 17' 6" x depth 11'
Home Theater:
282 sq/ft width 17' 6" x depth 16' 2"
Kitchen:
157 sq/ft width 10' 6" x depth 15'
Kitchen:
187 sq/ft width 21' 8" x depth 8' 8"
Laundry Room:
90 sq/ft width 10' x depth 9'
Master Bathroom:
232 sq/ft width 14' 4" x depth 16' 3"
Master Bedroom:
238 sq/ft width 14' x depth 17'
Master Sitting Area:
110 sq/ft width 11' x depth 10'
Porch - Front:
90 sq/ft width 18' x depth 5'
Sun Room:
88 sq/ft width 11' x depth 8'
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. **
- Kitchen and bath elevations: The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer.
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
| PDF Set : $1850.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| 5 Copy Set : $1950.00 |
5 printed plan sets mailed to you. |
| 5 Copy and PDF Set : $2200.00 |
5 printed plan sets mailed to you plus PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| CAD Set : $3700.00 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Foundation
| Basement: $299.00 |
Ideal for level lot, lower level of home partially or fully underground. |
| Daylight Basement: $299.00 |
Ideal for sloping lot, lower level of home partially underground. |
Framing
| Wood 2x4: $0.00 |
Wood 2x4 |
| Wood 2x6: $299.00 |
Wood 2x6 |
Additional Options
| Right-Reading Reverse : $199.00 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
| Additional Construction Sets : $75.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design : $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design : $200.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
*Alternate Foundations may take time to prepare.
