PLAN 413-149
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 84'
Height : 35' 5"
Width : 75' 10"
Area
First Floor: 2631 sq/ft height 10'
Second Floor: 2539 sq/ft height 9'
SubBasement Unfinished: 925 sq/ft
Ceiling
Main Ceiling : 10'
Upper Ceiling Ft : 9'
Roof
Primary Pitch : 14:12
Secondary Pitch : 6:12
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding/Stucco
Framing : 2"x4"
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Hobby Rec Room Game Room
Loft
Mud Room
Play Flex Room
Storage Area
Garage Features
Oversized Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Balcony
Grill Deck Sundeck
More
Jack & Jill Bath
Rooms
Bedroom 2:
184 sq/ft width 13' 2" x depth 14'
Bedroom 3:
206 sq/ft width 13' 4" x depth 15' 6"
Bedroom 4:
205 sq/ft width 13' 8" x depth 15'
Breakfast:
120 sq/ft width 12' x depth 10'
Dining Room:
210 sq/ft width 14' x depth 15'
Garage:
294 sq/ft width 14' x depth 21'
Great Room:
380 sq/ft width 20' x depth 19'
Guest Bedroom:
217 sq/ft width 14' 8" x depth 14' 10"
Kitchen:
437 sq/ft width 23' x depth 19'
Master Suite:
264 sq/ft width 13' x depth 20' 4"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$2400.00
$3380.00
$3380.00
Foundation
$0.00
$200.00
$400.00
$600.00
Additional Options
$100.00
$100.00
$39.00
$200.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
