Full Specs & Features
Depth : 70' 9"
Height : 31' 9"
Width : 106' 4"
Basement Living: 1986 sq/ft
First Floor: 2548 sq/ft
Primary Pitch : 12:12
Roof Framing : Truss
Roof Type : Asphalt
Exterior Wall Framing
Exterior Wall Finish : Shingle/Stone
Framing : Wood - 2x6
Formal Dining Room
Formal Living Room / Parlor
Main Floor Master Bedroom
Walk In Closet
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Great Room Living Room
Hobby Rec Room Game Room
Main Floor Laundry
Open Floor Plan
Unfinished Future Space
Vaulted / Cathedral Ceilings
189 sq/ft width 15' 2" x depth 12' 6"
292 sq/ft width 17' 9" x depth 16' 6"
180 sq/ft width 15' x depth 12'
195 sq/ft width 15' 5" x depth 12' 8"
277 sq/ft width 15' x depth 18' 6"
253 sq/ft width 14' 6" x depth 17' 6"
685 sq/ft width 25' x depth 27' 5"
368 sq/ft width 16' 3" x depth 22' 8"
223 sq/ft width 17' 8" x depth 12' 8"
262 sq/ft width 15' x depth 17' 6"
What's Included In This Plan Set
Please note: If you are building a Visbeen Architects design in the state of Michigan, please give us a call to confirm availability. Construction in the state of Michigan requires special permission from the Architect.
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
