Key Specs
4147
sq ft
5
Beds
3.5
Baths
2
Floors
3
Garages
Wow! Cost to Build Reports Only $4.99 with Code CTB2023 (Limit 1)
This report will provide you cost estimates based on location and building materials.
Phone: 1-877-222-1762
See our Terms & Conditions and Privacy Policy.
PLAN 23-294
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Floor Plans
Full Specs & Features
Dimension
Depth : 51'
Height : 36'
Width : 95'
Area
First Floor: 2502 sq/ft height 9'
Garage: 789 sq/ft
Second Floor: 1645 sq/ft
Ceiling
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Shingle
Secondary Pitch : 12:12
Exterior Wall Framing
Exterior Wall Finish : Stone
Framing : 2"x6"
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Additional Room Features
Loft
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Balcony
Covered Front Porch
Covered Rear Porch
Rooms
3rd BR Closet:
15 sq/ft width 7' 6" x depth 2'
Bathroom 2:
78 sq/ft width 14' 4" x depth 5' 6"
Bathroom 3:
124 sq/ft width 11' 4" x depth 11'
Bedroom 2:
207 sq/ft width 14' 4" x depth 14' 6"
Bedroom 2 Closet:
15 sq/ft width 7' 6" x depth 2'
Bedroom 3:
149 sq/ft width 14' x depth 10' 8"
Bedroom 3 Closet:
15 sq/ft width 7' 6" x depth 2'
Bedroom 4:
168 sq/ft width 11' 6" x depth 14' 8"
Bedroom 4 Closet:
37 sq/ft width 6' x depth 6' 4"
Bedroom 5:
176 sq/ft width 16' x depth 11'
Breakfast Room:
138 sq/ft width 14' 4" x depth 9' 8"
Dining Room:
192 sq/ft width 13' x depth 14' 10"
Foyer:
140 sq/ft width 14' x depth 10'
Garage:
713 sq/ft width 23' x depth 31'
Hall Closet:
5 sq/ft width 2' 6" x depth 2'
Kitchen:
164 sq/ft width 12' 8" x depth 13'
Living Room:
306 sq/ft width 18' x depth 17'
Master Bathroom:
190 sq/ft width 13' x depth 14' 8"
Master Bedroom:
322 sq/ft width 14' 8" x depth 22'
Master Closet:
91 sq/ft width 13' x depth 7'
Porch - Front:
316 sq/ft width 48' 8" x depth 6' 6"
Porch - Left:
71 sq/ft width 4' 8" x depth 15' 4"
Porch - Rear:
122 sq/ft width 14' 8" x depth 8' 4"
Powder Room:
30 sq/ft width 7' 8" x depth 4'
Study:
216 sq/ft width 13' x depth 16' 8"
Utility Room:
56 sq/ft width 7' 8" x depth 7' 4"
What's Included In This Plan Set
-
Exterior Elevations (front, rear, left & right sides) typically include:
- Floor and ceiling heights
- Dimensions of standard windows
- Dimensions of roof overhangs
- Location of all needed flashings (mention of “typical” in most cases)
- Height and location of foundation indicated in dashed lines
- Type of finishing and textures (we write siding, horizontal or vertical but not the company)
- Dimension and height of chimney (dimensions yes but the height is determined by the local building code)
- All exterior and interior dimensions
- Thickness of foundation walls (if variable)
- All the structures needed to hold the first level, columns with load applications, beam sizes, variations in floor joists and their exact location. (The load application is not present. Same for the beam, we mention they are but not the size because this can be changed as per manufacturer)
- Location of stairwell
- Location and sizes of windows
- Location and dimensions of footings (where applicable and required)
- All interior and exterior dimensions (included but not as a schedule)
- Location and sizes of doors and windows
- Indication of the structure above (second floor or roof)
- Indication of details that are available on other pages
- Location of all the different trusses needed
- The general overcharge of the roof compared to the floor footprint underneath
- All the different floor and ceiling heights
- Dimensions and design of trusses
- Dimensions and details of overhand
- Roof pitch on all truss sections
- Roof sections
- Sections of concrete wall with wood connection
- Section of walls with particulars called out
- Section of concrete porch and connection with wood frame
- Foundation particulars in the garage entrance
- Components of certain types of walls (ex: between garage and living quarters)
- All the details and components needed in the construction of a house, including window section in a typical wall, connection between floor and exterior wall with their components, type of beam used.
- Note: This plan does not include HVAC, electrical and plumbing.
Plan Set
$1882.75
$1989.00
$1989.00
$2392.75
Foundation
$0.00
$318.75
$318.75
$318.75
Additional Options
$170.00
$51.00
$85.00
$33.15
$170.00
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
