Plan Description


This classical design floor plan is 4049 sq ft and has 3 bedrooms and 4.5 bathrooms.

Full Specs & Features


Dimension

Depth : 77'

Height : 32'

Width : 62'

Area

Basement Unfinished: 2637 sq/ft

Bonus: 687 sq/ft

First Floor: 2637 sq/ft height 10'

Second Floor: 1412 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 10'

Upper Ceiling Ft : 9'

Roof

Primary Pitch : 10:12

Roof Framing : Conventional

Exterior Wall Framing

Exterior Wall Finish : Brick

Framing : Wood - 2x4

Bedroom Features

Guest Suite

Main Floor Master Bedroom

Split Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Eating Bar

Kitchen Island

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Family Room Keeping Room

Great Room Living Room

Loft

Play Flex Room

Storage Area

Garage Features

Oversized Garage

Side Entry Garage

Entryway

Friend S Entry

Lot Characteristics

Suited For Corner Lot

Suited For View Lot

Outdoor Spaces

Balcony

Covered Front Porch

Covered Rear Porch

Rooms

3rd BR Closet:

24 sq/ft width 6' x depth 4'

Basement Foundation:

3162 sq/ft width 62' x depth 51'

Bedroom 2:

270 sq/ft width 18' x depth 15'

Bedroom 2 Closet:

28 sq/ft width 2' x depth 14'

Bedroom 3:

270 sq/ft width 18' x depth 15'

Bedroom 3 Closet:

28 sq/ft width 2' x depth 14'

Bonus Room - Finished:

480 sq/ft width 16' x depth 30'

Breakfast Room:

100 sq/ft width 10' x depth 10'

Dining Room:

299 sq/ft width 13' x depth 23'

Foyer:

112 sq/ft width 8' x depth 14'

Game Room:

224 sq/ft width 16' x depth 14'

Garage:

780 sq/ft width 26' x depth 30'

Hall Bathroom:

286 sq/ft width 22' x depth 13'

Kitchen:

252 sq/ft width 14' x depth 18'

Living Room:

224 sq/ft width 16' x depth 14'

Master Bathroom:

221 sq/ft width 13' x depth 17'

Master Bedroom:

221 sq/ft width 13' x depth 17'

Master Closet:

136 sq/ft width 8' x depth 17'

Porch - Front:

352 sq/ft width 22' x depth 16'

Powder Room:

30 sq/ft width 6' x depth 5'

What's Included In This Plan Set


  • Cover Sheet: The cover sheet features an elevation of the home, sheet number index for the plan, and contact information.
  • Foundation: These drawings will detail and illustrate the foundation of the home, exterior and interior footings to support the floors and structure above. If a basement is purchased, it will show the stairs, bearing walls, and basement windows and doors.
  • First Floor Plan: This page is drawn to ¼”=1’-0” scale and includes exterior dimensions to build the home. The notes are precise directions for your builder. Important features such as built-ins, niches, and appliances are noted. Doors and windows are identified and specific sizing can be found on window and door schedules. *Framing is not included.
  • Second Floor Plan: The second floor includes stair details. Often the reflective roof detail is shown legibly over the second floor plan. This is helpful for the framing contractor. *Framing is not included.
  • Lighting and Electrical: On this sheet you have a schematic of the lights, electrical plugs, phone location, and code items such as smoke detectors. It is common place to build with your builder and/or electrician before the work starts to review this plan. Careful planning can make your home special and convenient for your family.
  • Second Floor Lighting: The same details as provided for the first floor.
  • Front and Rear Elevations: The front and rear elevations may be on separate pages depending on the size of the house. This page comes with exterior dimensions and notes required to complete construction. This is where the windows, doors, and interior trim details are illustrated, as well as wall heights, roof pitches and ridge heights.
  • Right and Left Elevations: The right and left elevations provide the same details as the front and rear elevations.
  • Roof Plan: This drawing, usually at ¼”=1’-0” scale, will be a bird’s eye view of the home. It will show the ridges, hips, and valleys. This page will show a beautifully designed roof.*Framing is not included.
  • Cross-Sections: Sections are used to further describe any architectural intent necessary for the builder or framer. This drawing will illustrate important changes in the floor, ceiling, and roof heights.
  • Cabinet Elevations*: Cabinet elevations are provided with your plans, and like the electrical plan, they are mainly a guide for estimating purposes. Cabinets are an area that is easy to customize and your builder or cabinet maker will work with you early on in the process to ensure that the correct cabinets are specified. Archival Designs believes cabinets should reflect your taste and budget. After framing and sheet rock installation sizes of walls may change slightly. The cabinet maker must take as built measurements to properly size your cabinets. **NOTE: The majority of house plans will include cabinet elevations in construction set; however, not all will include.
  • General Notes: Separate sheets that provide standard construction notes, in addition included are the details required to comply with International Residential Code (IRC) & Southern Building Code (SBC).
