PLAN 453-417
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 68' 6"
Height : 37'
Width : 64'
Area
First Floor: 2240 sq/ft
Garage: 560 sq/ft
Second Floor: 1343 sq/ft
Roof
Primary Pitch : 12:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Stucco
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Main Floor Master Bedroom
Kitchen Features
Breakfast Nook
Kitchen Island
Kitchenette Wet Bar
Additional Room Features
Hobby Rec Room Game Room
Loft
Main Floor Laundry
Storage Area
Sunroom
Garage Features
Side Entry Garage
Outdoor Spaces
Balcony
Deck
Screened Porch
Rooms
Bedroom 3:
143 sq/ft width 11' 6" x depth 12' 6"
Bedroom 4:
137 sq/ft width 12' 6" x depth 11'
Bedroom 5:
201 sq/ft width 11' 6" x depth 17' 6"
Breakfast Room:
94 sq/ft width 13' 6" x depth 7'
Den/Office or Bedroom 1:
143 sq/ft width 11' 6" x depth 12' 6"
Dining Room:
162 sq/ft width 12' 6" x depth 13'
Game Room:
324 sq/ft width 13' 6" x depth 24'
Garage:
517 sq/ft width 22' x depth 23' 6"
Garage Two:
755 sq/ft width 22' x depth 34' 4"
Gathering Room:
341 sq/ft width 19' 6" x depth 17' 6"
Master Bedroom:
229 sq/ft width 13' 6" x depth 17'
What's Included In This Plan Set
- Foundation Plan(s): Dimensioned and detailed foundation plan (type as listed on home plan description). Typical foundation details, wall sections, and cornice details necessary for construction.
- Floor Plan(s): Dimensioned and detailed floor plans
- Exterior Elevations: Views of the home from all four sides showing exterior materials, roof slope, ridge heights, siding and trim notes.
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
- Building Section(s): Shows the relationship between different levels, wall heights, and the overall building volume. May include details like foundation, framing, insulation, and finishes.
- Electrical Plan(s): Separate electrical plan (may be shown on floor plans in some cases). Shows the location of lights, receptacles, switches, etc.
- Construction Notes / Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
- Framing Detail(s): Framing plans (framing may be shown on floor plans in some cases.) If included, the framing layout is intended to be a suggested layout only. Design loads and weather conditions vary by region. As a result the size, spacing, and layout of all structural elements in this home design may need approval by a structural engineer or code official based on your specific site location.
Plan Set
$1402.50
$1402.50
Foundation
$0.00
Framing
$0.00
Additional Options
$51.00
$140.25
$335.75
$33.15
$140.25
$42.50
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
