PLAN 70-505
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 56'
Height : 30'
Width : 77' 8"
Area
First Floor: 1776 sq/ft height 9'
Second Floor: 1537 sq/ft
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding/Stucco
Framing : 2"x6"
Bedroom Features
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Loft
Master Sitting Area
Storage Area
Sunroom
Garage Features
Oversized Garage
Lot Characteristics
Suited For View Lot
Outdoor Spaces
Balcony
Covered Front Porch
Screened Porch
More
Jack & Jill Bath
Rooms
Bedroom 2:
126 sq/ft width 10' x depth 12' 8"
Bedroom 3:
139 sq/ft width 11' x depth 12' 8"
Bedroom 4:
149 sq/ft width 13' x depth 11' 6"
Den:
149 sq/ft width 11' 8" x depth 12' 10"
Dining Room:
149 sq/ft width 11' 8" x depth 12' 10"
Family Room:
344 sq/ft width 20' 8" x depth 16' 8"
Kitchen:
190 sq/ft width 13' x depth 14' 8"
Living Room:
143 sq/ft width 13' x depth 11'
Master Bedroom:
230 sq/ft width 13' 10" x depth 16' 8"
Nook:
140 sq/ft width 13' x depth 10' 10"
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
Plan Set
$1217.00
$1267.00
$1518.00
$1518.00
$2434.00
Foundation
$0.00
$395.00
$395.00
Additional Options
$395.00
$80.00
$100.00
$395.00
$39.00
$75.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
