PLAN 301-107
Key Specs
3161
sq ft
5
Beds
4
Baths
2
Floors
2
Garages
Cost to Build Reports Only $9.99 with Code CTB2022 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Phone: 1-877-222-1762
See our Terms & Conditions and Privacy Policy.
PLAN 301-107
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Full Specs & Features
Height : 33'
Width : 64' 4"
First Floor: 2556 sq/ft
Second Floor: 605 sq/ft
Roof Framing : Conventional
Roof Type : Shingle
Framing : 2"x4"
Walk In Closet
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Family Room Keeping Room
Loft
Storage Area
Unfinished Future Space
Courtyard
Covered Rear Porch
3rd BR Closet:
23 sq/ft width 5' 4" x depth 4' 6"
Bathroom 2:
40 sq/ft width 8' 2" x depth 5'
Bedroom 2:
162 sq/ft width 12' x depth 13' 6"
Bedroom 2 Closet:
width 0" x depth 2'
Bedroom 3:
144 sq/ft width 12' x depth 12'
Bedroom 3 Closet:
width 0" x depth 2'
Bedroom 4:
137 sq/ft width 11' x depth 12' 6"
Bedroom 4 Closet:
14 sq/ft width 2' x depth 7'
Bonus Room - Finished:
144 sq/ft width 12' x depth 12'
Breakfast Room:
148 sq/ft width 11' x depth 13' 6"
Dining Room:
251 sq/ft width 19' 4" x depth 13'
Foyer:
168 sq/ft width 17' 3" x depth 9' 9"
Garage:
441 sq/ft width 21' x depth 21'
Gathering Room:
229 sq/ft width 12' 9" x depth 18'
Kitchen:
270 sq/ft width 14' 3" x depth 19'
Living Room:
347 sq/ft width 19' 4" x depth 18'
Master Bathroom:
174 sq/ft width 21' x depth 8' 4"
Master Bedroom:
240 sq/ft width 15' x depth 16'
Master Closet:
48 sq/ft width 6' x depth 8'
Porch - Rear:
219 sq/ft width 18' 4" x depth 12'
Slab Foundation:
6862 sq/ft width 106' 8" x depth 64' 4"
Storage:
192 sq/ft width 17' x depth 11' 4"
Study:
162 sq/ft width 12' x depth 13' 6"
Utility Room:
73 sq/ft width 7' x depth 10' 6"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
| 5 Copy Set : $1134.00 |
5 printed plan sets mailed to you. |
| 8 Copy Set : $1239.00 |
8 printed plan sets mailed to you. |
| Reproducible Set : $1239.00 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
| Single Set : $924.00 |
One printed set for bidding purposes only. Not a legal building set for construction. |
Foundation
| Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
Additional Options
| Additional Construction Sets : $60.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design : $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design : $200.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
| Mirror Reversed Sets : $60.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
