PLAN 70-1323
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 48'
Height : 37'
Width : 76' 6"
Area
First Floor: 1745 sq/ft
Second Floor: 1100 sq/ft
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x6
Rooms
Breakfast Nook:
115 sq/ft width 11' x depth 10' 6"
Den:
182 sq/ft width 14' x depth 13'
Dining Room:
205 sq/ft width 15' x depth 13' 8"
Family Room:
270 sq/ft width 20' x depth 13' 6"
Garage:
808 sq/ft width 24' x depth 33' 8"
Kitchen:
200 sq/ft width 16' x depth 12' 6"
Living Room:
196 sq/ft width 14' x depth 14'
Sun Room:
186 sq/ft width 13' 8" x depth 13' 8"
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
Plan Set
$974.95
$1011.50
$1218.05
$1218.05
$1949.05
Foundation
$0.00
$335.75
$335.75
Framing
$0.00
Additional Options
$335.75
$68.00
$85.00
$33.15
$63.75
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
