PLAN 40-128
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 45' 10"
Height : 29'
Width : 84' 5"
Area
Bonus: 315 sq/ft
First Floor: 1850 sq/ft
Garage: 680 sq/ft
Second Floor: 854 sq/ft
Roof
Primary Pitch : 10:12
Roof Framing : Combination Truss/Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : 2"x4"
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Play Flex Room
Storage Area
Unfinished Future Space
Workshop
Lot Characteristics
Suited For View Lot
Outdoor Spaces
Covered Rear Porch
Wrap Around Porch
Rooms
Bedroom 2:
147 sq/ft width 12' x depth 12' 4"
Bedroom 3:
132 sq/ft width 12' x depth 11'
Bonus Room - Finished:
216 sq/ft width 21' x depth 10' 4"
Breakfast Room:
121 sq/ft width 11' x depth 11'
Dining Room:
168 sq/ft width 12' x depth 14'
Game Room:
217 sq/ft width 16' x depth 13'
Garage:
680 sq/ft width 21' x depth 22' 4"
Kitchen:
132 sq/ft width 11' x depth 12'
Living Room:
304 sq/ft width 19' x depth 16'
Master Bedroom:
234 sq/ft width 16' 9" x depth 14'
Porch - Front:
120 sq/ft width 20' x depth 6'
Porch - Rear:
120 sq/ft width 20' x depth 6'
Study:
154 sq/ft width 11' 8" x depth 14'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$845.00
$935.00
$1020.00
$1595.00
$745.00
Foundation
$0.00
$0.00
$0.00
Additional Options
$100.00
$50.00
$100.00
$39.00
$100.00
$50.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
