PLAN 1060-36
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Floor Plan - Main Floor
Floor Plan - Lower Floor
Full Specs & Features
Dimension
Depth: 38'
Height: 18' 7"
Width: 52' 4"
Area
Basement Living: 1367 sq/ft height 8'
First Floor: 1358 sq/ft height 8'
Garage: 475 sq/ft
Roof
Primary Pitch: 7:12
Roof Framing: Truss
Roof Type: Asphalt
Exterior Wall Framing
Exterior Wall Finish: Brick/Siding
Framing: Wood - 2x4
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Additional Room Features
Family Room Keeping Room
Main Floor Laundry
Media Room
Open Floor Plan
Garage Features
Front Entry Garage
Outdoor Spaces
Covered Front Porch
Rooms
Basement Family/ Media Room:
533 sq/ft width 38' 1" x depth 14'
Bath 2:
40 sq/ft width 8' x depth 5'
Bedroom 2:
100 sq/ft width 10' x depth 10'
Bedroom 3:
126 sq/ft width 11' 5" x depth 11'
Bedroom 4:
128 sq/ft width 10' x depth 12' 10"
Bedroom 4 Closet:
43 sq/ft width 5' 8" x depth 7' 6"
Bedroom 5:
137 sq/ft width 11' x depth 12' 5"
Covered Front Porch:
22 sq/ft
Craft Room:
177 sq/ft width 12' x depth 14' 9"
Dining Area:
160 sq/ft width 10' x depth 16'
Family Room:
210 sq/ft width 15' x depth 14'
Garage:
475 sq/ft width 21' x depth 21' 9"
Kitchen:
117 sq/ft width 11' 5" x depth 10' 3"
Laundry:
44 sq/ft width 8' x depth 5' 6"
Master Bath:
40 sq/ft width 8' x depth 5'
Master Bedroom:
180 sq/ft width 14' 10" x depth 12' 10"
What's Included In This Plan Set
- Cover Sheet: General Notes for framing, plumbing, electrical, window/egress, concrete, fastener schedule; plan index.
- Foundation Plan(s): This page shows all necessary notations and dimensions including footings, support columns, walls, and excavated/unexcavated areas.
- Floor Plan(s): Detailed plans for each level showing room dimensions, wall partitions, windows and doors, fixture locations, and ceiling treatments.
- Exterior Elevations: Views of the home from all four sides showing exterior materials, roof slope, ridge heights, siding and trim notes.
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Cross Section(s): Sectional details showing room and attached exterior details, floor-to-floor heights.
- Electrical Plan(s): Shows the location of lights, receptacles, switches, etc. with a legend.
- Detail Sheet(s): Roof vents, heel truss, soffit/ridge vents, stair framing, fasteners and connectors, flashing and air sealing (reference).
- Construction Notes and Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
- Framing Detail(s): If included, the framing layout is intended to be a suggested layout only. Will typically show joist direction, stair opening, bearing walls.
- Wall Section(s): Sectionals showing wall types and details.
- Energy Guidelines: Climate zone estimations by component; R-values, U-factors, SHGC, air barrier & insulation installation criteria table.
Plan Set
$950.00
$1195.00
$1350.00
$1495.00
$1650.00
$1950.00
Foundation
$350.00
$350.00
Framing
$0.00
$250.00
Additional Options
$195.00
$165.00
$295.00
$39.00
$165.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
