PLAN 928-83
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 35'
Height : 25'
Width : 74'
Area
Basement Living: 1058 sq/ft height 9'
First Floor: 1537 sq/ft height 9'
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Asphalt
Exterior Wall Framing
Exterior Wall Finish : Shingle
Framing : Wood - 2x4
Bedroom Features
Fireplace
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Additional Room Features
Family Room Keeping Room
Main Floor Laundry
Outdoor Spaces
Courtyard
Covered Front Porch
Deck
Rooms
Bedroom 2:
140 sq/ft width 11' x depth 12' 9"
Bedroom 3:
156 sq/ft width 12' x depth 13' 1"
Dining Room:
128 sq/ft width 11' 4" x depth 11' 4"
Family Room:
316 sq/ft width 24' 2" x depth 13' 1"
Garage:
497 sq/ft width 21' 4" x depth 23' 4"
Kitchen:
135 sq/ft width 9' 11" x depth 13' 8"
Living Room:
206 sq/ft width 14' 1" x depth 14' 8"
Master Bedroom:
178 sq/ft width 14' 8" x depth 12' 2"
Shop:
468 sq/ft width 20' 8" x depth 22' 8"
What's Included In This Plan Set
Please note: If you are building a Visbeen Architects design in the state of Michigan, please give us a call to confirm availability. Construction in the state of Michigan requires special permission from the Architect.
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Plan Set
$1270.75
$2970.75
Foundation
$0.00
Framing
$0.00
Additional Options
$165.75
$85.00
$33.15
$85.00
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
