Key Specs
2461
sq ft
4
Beds
2
Baths
1
Floors
2
Garages
Phone: 1-877-222-1762
See our Terms & Conditions and Privacy Policy.
Use Code CTBBF (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 929-595
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 67' 2"
Height : 27'
Width : 71' 2"
Area
Bonus: 397 sq/ft
First Floor: 2461 sq/ft
Roof
Primary Pitch : 10:12
Roof Framing : Conventional
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Split Bedrooms
Kitchen Features
Kitchen Island
Additional Room Features
Great Room Living Room
Sunroom
Garage Features
Side Entry Garage
Outdoor Spaces
Covered Front Porch
Screened Porch
Rooms
3rd BR Closet:
24 sq/ft width 5' 4" x depth 4' 8"
Bathroom 2:
60 sq/ft width 12' x depth 5'
Bedroom 2 Closet:
12 sq/ft width 6' 4" x depth 2'
Bedroom 3:
147 sq/ft width 12' x depth 12' 4"
Bedroom 3 Closet:
12 sq/ft width 6' 4" x depth 2'
Bedroom 4:
151 sq/ft width 13' 4" x depth 11' 4"
Bedroom 4 Closet:
22 sq/ft width 2' x depth 11' 4"
Bonus Room - Finished:
298 sq/ft width 18' 8" x depth 16'
Breakfast Room:
123 sq/ft width 12' x depth 10' 4"
Deck:
87 sq/ft width 12' x depth 7' 4"
Dining Room:
197 sq/ft width 12' x depth 16' 5"
Foyer:
85 sq/ft width 13' 6" x depth 6' 4"
Garage:
476 sq/ft width 22' 8" x depth 21'
Garage Storage:
21 sq/ft width 5' 4" x depth 4'
Gathering Room:
354 sq/ft width 18' 8" x depth 19'
Hall Closet:
9 sq/ft width 4' 10" x depth 2'
Kitchen:
176 sq/ft width 12' x depth 14' 8"
Master Bathroom:
132 sq/ft width 9' x depth 14' 8"
Master Bedroom:
248 sq/ft width 13' 4" x depth 18' 8"
Master Closet:
92 sq/ft width 9' x depth 10' 4"
Porch - Front:
81 sq/ft width 15' 9" x depth 5' 2"
Study:
185 sq/ft width 12' x depth 15' 5"
Utility Room:
56 sq/ft width 9' x depth 6' 4"
