Full Specs & Features
Depth : 67' 7"
Height : 27'
Width : 46' 3"
First Floor: 2070 sq/ft height 9'
Primary Pitch : 9:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Formal Dining Room
Additional Room Features
Great Room Living Room
Covered Front Porch
Covered Rear Porch
3rd BR Closet:
12 sq/ft width 2' x depth 6'
45 sq/ft width 9' x depth 5'
152 sq/ft width 12' 8" x depth 12'
119 sq/ft width 11' x depth 10' 10"
150 sq/ft width 13' 8" x depth 11'
53 sq/ft width 8' x depth 6' 8"
441 sq/ft width 21' x depth 21'
14 sq/ft width 7' x depth 2'
348 sq/ft width 18' 4" x depth 19'
6 sq/ft width 2' x depth 3'
147 sq/ft width 13' x depth 11' 4"
114 sq/ft width 12' 8" x depth 9'
210 sq/ft width 15' x depth 14'
18 sq/ft width 3' x depth 6'
Porch - Front:
50 sq/ft width 8' x depth 6' 4"
Porch - Rear:
1248 sq/ft width 16' x depth 78'
139 sq/ft width 12' 8" x depth 11'
42 sq/ft width 7' x depth 6'
What's Included In This Plan Set
This designer charges $49.00 to review plan changes and prepare an estimate for your modifications.
This fee can be applied to your plan modifications once you move forward with the service. Please call if you would like to order a Plan Modification quote.
Purchasing a CAD set gives you an unlimited build license. All other plan sets, excluding the Single Set for bidding purposes, allow you to build the home one time.
