PLAN 1016-15
Key Specs
1898
sq ft
4
Beds
2.5
Baths
2
Floors
2
Garages
Cost to Build Reports Only $19.99 for a Limited Time!
This report will provide you cost estimates based on location and building materials.
Phone: 1-877-222-1762
See our Terms & Conditions and Privacy Policy.
PLAN 1016-15
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.Plan Description
Full Specs & Features
Height : 26'
Width : 68' 5"
Second Floor: 716 sq/ft
Roof Framing : Conventional
Framing : Wood - 2x6
Formal Dining Room
3rd BR Closet:
17 sq/ft width 2' 4" x depth 7' 4"
Attic:
242 sq/ft width 11' x depth 22'
Basement Foundation:
1073 sq/ft width 37' x depth 29'
Bedroom 3:
191 sq/ft width 14' 4" x depth 13' 4"
Bedroom 4:
164 sq/ft width 14' 10" x depth 11' 1"
Bedroom 4 Closet:
18 sq/ft width 2' 8" x depth 7'
Breakfast Room:
65 sq/ft width 7' 8" x depth 8' 6"
Deck:
184 sq/ft width 8' x depth 23'
Dining Room:
144 sq/ft width 11' 3" x depth 12' 10"
Foyer:
40 sq/ft width 5' 4" x depth 7' 8"
Garage:
462 sq/ft width 22' x depth 21'
Hall:
width 4' 3" x depth 0"
Hall Bathroom:
55 sq/ft width 5' 4" x depth 10' 4"
Hall Closet:
6 sq/ft width 2' x depth 3'
Kitchen:
85 sq/ft width 10' x depth 8' 6"
Laundry Room:
54 sq/ft width 5' 10" x depth 9' 4"
Master Bathroom:
61 sq/ft width 6' x depth 10' 4"
Master Bedroom:
192 sq/ft width 12' 10" x depth 15'
Master Closet:
22 sq/ft width 3' 8" x depth 6' 3"
Porch - Front:
111 sq/ft width 12' x depth 9' 4"
Powder Room:
18 sq/ft width 3' x depth 6' 4"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
| 5 Copy Set
: $770.00 |
5 printed plan sets mailed to you. |
| 8 Copy Set
: $835.00 |
8 printed plan sets mailed to you. |
| PDF Set
: $935.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| Reproducible Set
: $980.00 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
Foundation
| Basement: $0.00 |
Ideal for level lot, lower level of home partially or fully underground. |
Framing
| Wood 2x6: $0.00 |
Wood 2x6 |
Additional Options
| Additional Construction Sets
: $60.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design
: $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide
: $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design
: $100.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
| Mirror Reversed Sets
: $60.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
