PLAN 419-167

Key Specs


1785
sq ft

3
Beds

2.5
Baths

2
Floors

2
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.

Floor Plans


Floor Plan - Main Floor Plan
Reverse
Save
Floor Plan - Upper Floor Plan
Reverse
Save

Full Specs & Features


Dimension
Depth : 52'
Height : 31'
Width : 26'
Area
First Floor: 717 sq/ft height 9'
Garage: 458 sq/ft
Second Floor: 1068 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 6:12
Roof Framing : Conventional
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : 2"x4"
Bedroom Features
Upstairs Master Bedrooms
Walk In Closet
Additional Room Features
Family Room Keeping Room
Master Sitting Area
Storage Area
Garage Features
Rear Entry Garage
Rear Garage
Lot Characteristics
Suited For Narrow Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
