PLAN 18-1057

Key Specs


1511
sq ft

3
Beds

2
Baths

1
Floors

2
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-877-222-1762 for assistance.

Floor Plans


Floor Plan - Main Floor Plan
Reverse
Save Ranch Floor Plan - Main Floor Plan Plan #18-1057
Floor Plan - Main Floor Plan
Reverse
Save Ranch Floor Plan - Main Floor Plan Plan #18-1057

Full Specs & Features


Dimension
Depth : 48'
Height : 23'
Width : 54' 6"
Area
Basement Unfinished: 1479 sq/ft
First Floor: 1511 sq/ft height 9'
Garage: 420 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Main Ceiling : 9'
Roof
Primary Pitch : 9:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : 2"x6"
Bedroom Features
Split Bedrooms
Walk In Closet
Kitchen Features
Kitchen Island
Additional Room Features
Great Room Living Room
Unfinished Future Space
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch

What's Included In This Plan Set


See a sample plan set All plans are drawn at ¼” scale or larger and include :
  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
» See important information before purchasing.

Plan Set

PDF Set :
$877.80
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
5 Copy Set :
$987.53
5 printed plan sets mailed to you.
8 Copy Set :
$1097.25
8 printed plan sets mailed to you.
Reproducible Set :
$1097.25
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.
CAD Set :
$1755.60
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Single Set :
$768.08
One printed set for bidding purposes only. Not a legal building set for construction.

Foundation

Basement:
$0.00
Ideal for level lot, lower level of home partially or fully underground.
Slab:
$0.00
Ideal for level lot, single layer concrete poured directly on grade.

Additional Options

Right-Reading Reverse :
$166.25
Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Construction Sets :
$57.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Additional Use License :
$399.00
Additional Use License.
Audio Video Design :
$95.00
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide :
$37.05
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Home Furniture Planner :
$18.05
This fun visual aid lets you peel-and-stick furniture on a generic layout to plan out spacing.
Lighting Design :
$95.00
Receive an overlay sheet with suggested placement of lighting fixtures.
Material List :
$80.75
A list of building supplies needed to construct the infrastructure of your new house.
Mirror Reversed Sets :
$57.00
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.
Unlimited Use License :
$798.00
Unlimited Use License.

*Alternate Foundations may take time to prepare.

*Options with a fee may take time to prepare. Please call to confirm.
